QuadraLine RFID reader
Specifications
Badge types: Mifare UID (4, 7 and 10 byte ID) and EM-4100/4200
Power in: 12-24 Vdc
Maximum power consumption: 12 VDC: 170mA - 24 VDC: 85mA
Main network: RS 485
Signalization: Indicative beeper
Indicators: 5 indicative 24bit LEDs (16.8M colors)
- 4 LEDs behind card reader logo
- 1 LED as power (safety) indication behind logo
Status indication: CPU and Status LED (only visible during service)
Relays: 1 relay 1A, 30Vdc - 0.5A, 125Vac (resistive load) with common, normally open, normally closed contact
Digital input: 1
Front panel: Glass
Operating temperature: -10°C to +60°C
Dimensions: (W x H x D): 80 x 80 x 14.2 mm
Mounting boxes: Type Helia-9064-01 and Helia-276
